Product Summary
The EE80C196KC-20 is a high performance member of the MCSE 96 microcontroller. The EE80C196KC-20 is an enhanced 80C196KB device with 488 bytes RAM, 16 and 20 MHz operation and an optional 16 Kbytes of ROM/OTPROM.
Parametrics
Absolute maximum ratings: (1)Ambient Temperature: Under Bias:-55℃ to +125℃; (2)Storage Temperature:-65℃ to +150℃; (3)Voltage On Any Pin to VSS:-0.5V to +7.0V; (4)Voltage from EA or VPP to VSS or ANGND:+13.00V; (5)Power Dissipation:1.5W.
Features
Features: (1)16 and 20 MHz Available; (2)488 Byte Register RAM; (3)Register-to-Register Architecture; (4)28 Interrupt Sources/16 Vectors; (5)Peripheral Transaction Server; (6)1.4μs 16 x 16 Multiply (20 MHz); (7)2.4μs 32/16 Divide (20 MHz); (8)Powerdown and Idle Modes; (9)Five 8-Bit I/O Ports; (10)16-Bit Watchdog Timer; (11)Extended Temperature Available; (12)Full Duplex Serial Port; (13)High Speed I/O Subsystem; (14)16-Bit Timer; (15)16-Bit Up/Down Counter with Capture; (16)3 Pulse-Width-Modulated Outputs; (17)Four 16-Bit Software Timers; (18)8- or 10-Bit A/D Converter with Sample/Hold.
Diagrams
 |
