Product Summary

The PI5C3383QEX is a 5-bit, 4-port bus switch with exchange designed with a low On-Resistance allowing inputs to be connected directly to outputs. The switch creates no additional propagational delay or additional ground bounce noise.

Parametrics

Absolute maximum ratings: (1)Storage Temperature: –65℃ to +150℃; (2)Ambient Temperature with Power Applied: –40℃ to +85℃; (3)Supply Voltage to Ground Potential (Inputs & VCC Only): –0.5V to +7.0V; (4)Supply Voltage to Ground Potential (Outputs & D/O Only): –0.5V to +7.0V; (5)DC Input Voltage: –0.5V to +7.0V; (6)DC Output Current: 120 mA; (7)Power Dissipation: 0.5W.

Features

Features: (1)Near-Zero propagation delay; (2)5Ω switches connect inputs to outputs; (3)Direct bus connection when switches are ON; (4)Ultra-low quiescent power (0.2μA typical): Ideally suited for notebook applications; (5)Packaging (Pb-free & Green available): 24-pin 173-mil wide plastic TSSOP (L), 24-pin 150-mil wide plastic QSOP (Q), 24-pin 300-mil wide plastic SOIC (S).

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
PI5C3383QEX
PI5C3383QEX
Pericom
Universal Bus Functions 5B 4 Port Swabble Bus Switch
Data Sheet
Negotiable
